Khoom nta
Zoo heev low -kub cuam tshuam toughness (core kom zoo dua)
Lub ntsiab kom zoo dua ntawm ASTM A333 yog nyob rau hauv nws zoo heev uas tsis muaj - kub tej yam toughness. Qhov kev qhia tshwj xeeb no tso cai rau Charpy V- qhov ntsuas qhov cuam tshuam ntawm cov khoom ntawm qhov ntsuas kub tsis tshua muaj, ua kom muaj kev tiv thaiv txaus rau cov pob txha tawg nyob rau hauv qis - qhov kev pabcuam kub. Qib 6 muaj qhov cuam tshuam nruab nrab ntawm lub zog loj dua lossis sib npaug ntawm 18J thiab qhov tsawg kawg nkaus tus nqi ntawm Greater dua lossis sib npaug ntawm 13J ntawm -46 degree, txo qis kev pheej hmoo ntawm kev tawg ntawm cov ntaub ntawv ntawm qhov kub thiab txias thiab ua kom muaj kev nyab xeeb thiab kev ntseeg siab ntawm cov kav xa dej thaum muaj kev kub ntxhov.
Kev ua haujlwm vuam zoo
Qhov qis carbon sib npaug tsim ntawm ASTM A333 ua kom zoo weldability nrog cov txheej txheem vuam uas paub tab, ua rau nws haum rau loj - nplai ntawm - qhov chaw teeb tsa. Thaum welding qis-kub steel, yuav tsum tau tswj xyuas nruj ntawm cov cua sov tawm tswv yim los tiv thaiv kom tsis txhob muaj qhov hnyav ntawm cov cua sov- thaj tsam cuam tshuam. Preheating feem ntau tsis tsim nyog ua ntej welding (tshwj tsis yog rau cov kav dej tuab -cov kav dej lossis hauv qhov chaw qis - qhov kub thiab txias), thiab tom qab-weld kev kho cua sov ntawm 600-650℃tuaj yeem xaiv tau tom qab vuam kom txo qis kev ntxhov siab.
Zoo machinability
Nws tuaj yeem dhau los ua ntau yam txheej txheem xws li kub dabtsi yog khoov, txias khoov, thiab forging, ua rau nws tsim nyog rau kev tsim cov yeeb nkab fittings xws li lub luj tshib, tees, thiab reducers. Nws tseem tuaj yeem ua machined siv cov pa machining txoj kev. Nws yuav tsum raug sau tseg tias Qib 3 (3.5% Ni) thiab 8 (9% Ni), vim lawv cov ntsiab lus nickel ntau dua, muaj qhov ua haujlwm siab dua me ntsis piv rau Qib 6.
Cov thev naus laus zis paub tab thiab kev ntseeg siab ntev ntev -
Nws qhia txog kev ruaj ntseg zoo nyob rau lub sijhawm ntev -kev pabcuam nyob rau hauv lawv qhov ntsuas qhov ntsuas kub (Qib 6 Tsawg dua lossis sib npaug rau -46℃/ Qib 3 Tsawg dua lossis sib npaug rau -101℃/ Qib 8 Tsawg dua lossis sib npaug rau -196℃). Xa nyob rau hauv normalized los yog normalized ntxiv rau tempered mob, nws ua tiav ib tug uniform thiab zoo microstructure, ua kom lub koom haum stability thiab kev cia siab rau nyob rau hauv lub low-temperature kev pab cuam.
Technical Specifications
Tshuaj muaj pes tsawg leeg (ASTM A333 / ASME SA333)
|
Lub ntsiab |
Qib 1 |
Qib 3 |
Qib 4 |
Qib 6 |
Qib 7 |
Qib 8 |
Qib 9 |
Nco tseg |
|
C |
Tsawg dua lossis sib npaug li 0.30% |
Tsawg dua lossis sib npaug li 0.19% |
Tsawg dua lossis sib npaug li 0.12% |
Tsawg dua lossis sib npaug li 0.30% |
Tsawg dua lossis sib npaug li 0.19% |
Tsawg dua lossis sib npaug li 0.13% |
Tsawg dua lossis sib npaug li 0.20% |
Xyuas kom qis -kub toughness thiab weldability |
|
Mn |
0.40-1.06% |
0.31-0.64% |
0.50-1.05% |
0.29-1.06% |
Tsawg dua lossis sib npaug li 0.90% |
Tsawg dua lossis sib npaug li 0.90% |
0.40-1.06% |
Kev daws teeb meem ntxiv dag zog, txhim kho lub zog |
|
P |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Cov khoom tsis zoo, tswj nruj heev |
|
S |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Tsawg dua lossis sib npaug li 0.035% |
Cov khoom tsis zoo, tswj nruj heev |
|
Si |
0.10-0.35% |
0.13-0.32% |
0.18-0.37% |
Ntau dua lossis sib npaug li 0.10% |
0.13-0.32% |
0.13-0.32% |
0.13-0.32% |
Deoxidizer |
|
Ni |
- |
3.18-3.82% |
0.47-0.98% |
- |
2.03-2.57% |
8.40-9.60% |
1.60-2.24% |
Cov ntsiab lus ntawm Tsawg-Tsub Toughness |
|
Cr |
- |
- |
0.44-1.01% |
- |
- |
- |
- |
Txhim kho hardenability |
|
Cu |
- |
- |
0.40-0.70% |
- |
- |
- |
- |
Txhim kho corrosion kuj |
|
Mo |
- |
- |
0.40-0.75% |
- |
- |
- |
- |
Txhim kho siab -kub muaj zog |
|
Fe |
Cov khoom seem |
Cov khoom seem |
Cov khoom seem |
Cov khoom seem |
Cov khoom seem |
Cov khoom seem |
Cov khoom seem |
Matrix element |
Lub cev muaj zog
|
Kev ua tau zoo |
Tus lej Tus Nqi / Ntau |
Cov xwm txheej kuaj |
|
Qhov ntom |
7.85 g / cm³ |
Chav tsev kub (20 degree) |
|
Melting Point |
≈ 1420-1460 degree |
- |
|
Elastic modulus |
Qhov siab tshaj plaws ntawm qhov siab ntawm 200 GPa |
Chav kub |
|
Thermal conductivity |
≈ 50 W/(m·K) |
Chav kub |
|
Coefficient ntawm thermal expansion (20-100 degree) |
≈ 11.7 × 10⁻⁶ /K |
- |
|
Poisson tus ratio |
≈ 0.28 |
Chav kub |
|
Magnetism |
Ferromagnetic |
Cov pa roj carbon steel / qis- alloy steel, uas yog hlau nplaum |
Mechanical Properties (Tswj tus nqi, ASTM A333)
|
Kev ua tau zoo |
Qib 1 |
Qib 3 |
Qib 4 |
Qib 6 |
Qib 7 |
Qib 8 |
Qib 9 |
Specification |
|
Tensile zog |
Ntau dua lossis sib npaug li 380 MPa |
Ntau dua lossis sib npaug li 450 MPa |
Ntau dua lossis sib npaug li 415 MPa |
Ntau dua lossis sib npaug li 415 MPa |
Ntau dua lossis sib npaug li 450 MPa |
Ntau dua lossis sib npaug li 690 MPa |
Ntau dua lossis sib npaug li 435 MPa |
ASTM A333 Cov khoom lag luam |
|
Yield zog |
Ntau dua lossis sib npaug li 205 MPa |
Ntau dua lossis sib npaug li 240 MPa |
Ntau dua lossis sib npaug li 240 MPa |
Ntau dua lossis sib npaug li 240 MPa |
Ntau dua lossis sib npaug li 205 MPa |
Ntau dua lossis sib npaug li 515 MPa |
Ntau dua lossis sib npaug li 315 MPa |
ASTM A333 Cov khoom lag luam |
|
Elongation |
Ntau dua lossis sib npaug li 35% |
Ntau dua lossis sib npaug li 30% |
Ntau dua lossis sib npaug li 30% |
Ntau dua lossis sib npaug li 30% |
Ntau dua lossis sib npaug li 30% |
Ntau dua lossis sib npaug li 22% |
Ntau dua lossis sib npaug li 28% |
ASTM A333 Cov khoom lag luam |
|
Impact test kub |
-46 degree |
-101 degree |
-46 degree |
-46 degree |
-73 degree |
-196 degree |
-73 degree |
ASTM A333 Cov khoom lag luam |
|
Impact Toughness (nruab nrab tus nqi) |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 18J |
ASTM A333 Cov khoom lag luam |
Ceeb Toom: Qib 6 yog qib siv dav tshaj plaws hauv ASTM A333 tus qauv, muab qhov sib npaug zoo ntawm lub zog, weldability, qis - qhov kub thiab txias, thiab tus nqi, haum rau qis - qhov kub thiab txias kev pab cuam mus txog -46℃. Qib 3 (3.5% Ni) muaj feem xyuam rau -101 degree, thiab Qib 8 (9% Ni) rau -196 degree.
Tsawg-kub Impact Performance (Core Indicator)
|
Qib |
Yam tsawg kawg nkaus ua haujlwm kub |
Impact test kub |
Yam tsawg kawg nkaus lub zog (nruab nrab tus nqi) |
Yam tsawg kawg nkaus lub zog (tus nqi ib leeg) |
Tej kev siv |
|
Qib 1 |
-46 degree |
-46 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
General low -kub tej yam kev mob |
|
Qib 3 |
-101 degree |
-101 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
LNG, cua cais chav tsev |
|
Qib 4 |
-46 degree |
-46 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
Tsawg-kub sulfur- muaj ib puag ncig |
|
Qib 6 |
-46 degree |
-46 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
Feem ntau siv, nyiam rau -46℃qis-kub |
|
Qib 7 |
-73 degree |
-73 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
Qhov ntsuas kub qis dua |
|
Qib 8 |
-196 degree |
-196 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
LNG cia tso tsheb hlau luam, kua nitrogen / kua oxygen pipelines |
|
Qib 9 |
-73 degree |
-73 degree |
Ntau dua lossis sib npaug rau 18J |
Ntau dua lossis sib npaug rau 13J |
Petrochemical sib sib zog nqus cryogenic khoom |
Kev kho cua sov
normalizing
Kub rau 845-925 degree, tuav lub sijhawm txaus, ces cua txias. Qhov no ua rau muaj qhov sib xws thiab zoo -grained microstructure, txhim kho qhov kub thiab txias toughness. Qhov normalizing kub rau Qib 8 feem ntau yog 845-900 degree, me ntsis siab dua lwm qib.
Normalizing + Tempering (pom zoo rau qib 8)
Tom qab normalizing, kub rau 565-650℃rau tempering, ces cua txias. Qhov no tshem tawm normalizing kev nyuaj siab thiab ntxiv optimizes low-temperature toughness.
Tag nrho Annealing (Yeem)
Thaum tshav kub kub mus rau 815-870 degree, tuav ntawm qhov kub thiab txias, tom qab ntawd lub qhov cub txias kom txog li 650 degree, tom qab ntawd cua txias rau chav sov. Siv los tshem tawm cov kev ntxhov siab ua haujlwm txias lossis txhim kho kev ua haujlwm txias.
Tshaj tawm -Kev kho cua sov (PWHT, xaiv raws li phab ntsa tuab thiab kev ua haujlwm)
Tshav kub rau 600-650 degree, tuav ntawm qhov kub thiab txias, tom qab ntawd maj mam txias kom tshem tawm qhov seem welding stresses.
Siv tau Media
Liquefied Natural Gas (LNG)
LNG txais terminals, qis -kub pipelines ntawm liquefaction nroj tsuag (tsawg dua los yog sib npaug rau -162 degree)
Cua cais chav tsev
kua oxygen, kua nitrogen, kua argon pipelines thiab cov kav dej txias
Tsawg- cov kua dej kub
Kev thauj mus los ntawm tsawg-kub xov xwm xws li kua ethylene, kua ammonia, thiab kua hydrogen
Petrochemical Deep Cryogenics
Sib sib zog nqus Cryogenic ntawm Ethylene Nroj Tsuag, Tsawg -Tub Txheej Txheej Piping
Tsawg-Tub kub Cia Tank
LNG cia tank pipelines, qis -kub kheej kheej tanks
Nco tseg:Txhua qib ntawm ASTM A333 muaj qhov sib txawv ntawm qhov ntsuas kub tsawg kawg nkaus. Qib 6 yog qhov tsim nyog rau qhov kub siab tshaj -46 degree, Qib 3 rau siab dua -101 degree, thiab Qib 8 rau siab dua -196 degree. Thaum xaiv cov ntaub ntawv, cov qib tsim nyog yuav tsum tau xaiv raws li qhov tsawg kawg nkaus tsim kub. Nws tsis muaj feem xyuam rau qhov kub thiab txias (siab tshaj 350 degree) thiab muaj zog corrosive media xws li oxidizing acids.
ASTM A333 yog qhov tsim nyog rau qis- kev pabcuam kub txij li -46℃txog -196℃thiab pom zoo siv rau hauv cov chaw hauv qab no:
Daim ntawv thov teb
-
LNG txais terminals thiab liquefaction nroj tsuag (cov ntawv thov tseem ceeb, Qib 3 / Qib 8)
● LNG unloading pipelines, vapor (BOG) pipelines
● LNG txoj kev thauj mus los (tsawg dua lossis sib npaug li -162 degree)
● LNG Tank Nrog Pipeline System -
Kev sib cais ntawm huab cua thiab muaj roj (Core Applications, Qib 6 / Qib 3)
● Ua kua Oxygen, Kua Nitrogen, thiab kua Argon Piping Systems (-183℃~ -196 degree)
● Txias Box Piping Systems rau Cov Cuab Yeej Sib Nqus
● Tsawg-Tub Piping rau Cov Khoom Siv Hluav Taws Xob Hluav Taws Xob -
Petrochemical Deep Cryogenics (Core Applications, Qib 6 / Qib 7 / Qib 9)
● Deep Cryogenic Separation Pipelines rau Ethylene Cracking Units (-100℃~ -160 degree)
● Tsawg-cov kav dej kub thauj mus los rau propylene thiab butadiene
● Tsawg-kub methanol ntxuav (Rectisol) txheej txheem piping -
Tsawg- qhov kub thiab txias cia thiab kev thauj mus los
● Piping system rau qis -kub kua tank tank
● Filling pipeline system rau qis -kub tank tsheb
● Cov kav dej rau cov nkoj thauj roj liquefied -
Tsawg-kub yeeb nkab fittings
● Tsawg-lub luj tshib kub, tees, reducers
● Tsawg-kub forged yeeb fittings, flanges
Kev xa khoom thiab Customization
Peb muab cov kev daws teeb meem hloov tau yooj yim thiab txhim khu kev qha los xyuas kom meej tias koj tau txais ASTM A333 qis-kub seamless steel kav uas zoo kawg nkaus phim koj qhov kev xav tau.
Customizable cov ntaub ntawv
Peb txhawb tsim ntau yam yooj yim thiab tshwj xeeb cov duab raws li drawings los yog specifications.
|
Daim ntawv |
 Kub- dov seamless steel yeeb nkab
|
 Txias- kos seamless steel yeeb nkab
|
 Loj -inch tuab-walled yeeb nkab
|
|---|---|---|---|
|
Pauv ntau yam |
Txoj kab uas hla: 60.3 - 1067 hli; Phab ntsa Thickness: 3 - 150 hli |
Sab nraud txoj kab uas hla: 10.3 - 114.3 hli; Phab ntsa Thickness: 1 - 15 hli |
Sab nraud txoj kab uas hla: 219 - 1067 hli; Phab ntsa Thickness: 20 - 150 hli |
|
Customization Muaj peev xwm |
Tsau -ntev txiav, bevel ua, yeeb nkab kawg threads, normalized / annealed mob |
Precision Dimension Control, Bright Annealing, Tsau -Length Txiav |
Kub nthuav dav ntawm cov raj, tsau -ntev txiav, bevel machining |
Vim li cas thiaj xaiv peb? - Txhim khu kev qha Engineering Technology. Dependable xa khoom.
Peb tsis yog ib tus neeg muag khoom xwb, tab sis yog ib tus neeg koom tes nrog cov ntaub ntawv ntseeg siab rau koj hauv Suav teb.
Vertically Integrated Production
Muaj 20,000㎡ qhov chaw nrog 10+ automated kab (8, 000+ tons / xyoo). Hauv - tsev cuab yeej & qhov chaw tuag ua rau muaj kev hloov kho sai thiab tswj tus nqi zoo - tsis muaj tus neeg nruab nrab kos npe.
Kev Tswjhwm nruj nruj ntawm txhua theem
Tag nrho traceability nyob rau hauv lub tseem ceeb QC checkpoints thoob plaws hauv ntau lawm . 100% raws li ASTM/ASME, EN, thiab GB qauv. Cov ntaub ntawv xeem cov ntaub ntawv muaj nyob nrog txhua qhov khoom xa tuaj.
Txhim khu kev xa khoom & Export ntim
10+ xyoo xa tawm mus rau Tebchaws Europe, North America, Southeast Asia & Middle East nrog cov dej tsis zoo thiab tiv thaiv- xeb, ua ke nrog cov kev xaiv thauj khoom yooj yim kom muaj kev nyab xeeb thiab nyob rau - lub sijhawm tuaj txog.
Qauv validation ua ntej pawg ntau lawm
Peb muab cov qauv dawb rau kev kuaj xyuas zoo, tso cai rau koj tso cov xaj xaj tsuas yog tom qab kev pom zoo. Peb xyuas kom meej qhov sib xws los ntawm cov qauv mus rau cov khoom loj los ntawm qhov ntsuas qhov tseeb thiab kev tsim pob tshab.
FAQ
Q: Dab tsi yog qhov zoo ntawm ASTM A333 Qib 6?
Q: Qhov txawv ntawm ASTM A333 Qib 6 thiab ASTM A106 Qib B yog dab tsi? Yuav ua li cas xaiv ntawm lawv?
Q: Yuav ua li cas xaiv cov qib siv feem ntau ntawm ASTM A333?
Q: Dab tsi yog qhov tsawg kawg nkaus kev pabcuam kub rau ASTM A333 Qib 6?
Q: Qhov kev ua tau zoo ntawm ASTM A333 Qib 6 yog dab tsi?
Q: Dab tsi yog qhov corrosion kuj ntawm ASTM A333 Qib 6?
