Khoom nta
Kev ua tau zoo tag nrho thiab tus nqi siab -effectiveness (core kom zoo dua)
Qhov txiaj ntsig tseem ceeb ntawm API 5L Gr.B nyob hauv nws qhov kev ua tau zoo tag nrho thiab tus nqi siab - ua tau zoo. Ua tsaug rau nws cov qauv qis -carbon tsim (cov ntsiab lus carbon tsawg dua lossis sib npaug li 0.26%) thiab cov ntsiab lus ntawm cov alloy nruab nrab, Gr.B muab cov nqi tsim khoom qis dua thaum ua kom lub zog qis tshaj ntawm 245 MPa thiab lub zog tensile yam tsawg kawg nkaus ntawm 415 MPa. Qhov no ua rau nws xaiv cov khoom siv yooj yim tshaj plaws rau kev tsim hluav taws xob.
|
Performance indicators, As |
PSL1 Cov Lus Qhia |
PSL2 Cov Lus Qhia |
|
Yam tsawg kawg nkaus tawm lub zog (MPa) |
245 |
245 |
|
Maximum Yield zog (MPa) |
- |
450 |
|
Yam tsawg kawg Tensile Strength (MPa) |
415 |
415 |
|
Maximum Tensile zog (MPa) |
- |
655 |
|
Yield ratio |
- |
Feem ntau Tsawg dua lossis sib npaug rau 0.93 |
|
Elongation |
Ntau dua lossis sib npaug li 30% |
Ntau dua lossis sib npaug li 30% |
Nco tseg: PSL2 txwv kev txwv ntawm ob qho tib si lub zog siab tshaj plaws thiab lub zog tensile siab tshaj plaws (nrog rau kev txwv siab ntawm 450 MPa thiab 655 MPa raws li), ua kom cov khoom muaj peev xwm deformation yas txaus thiab muaj kev nyab xeeb dua.
Kev ua tau zoo welding zoo (qhov yuav tsum tau muaj rau cov kav dej hlau)
Qhov qis carbon sib npaug tsim ntawm API 5L Gr.B ua kom cov vuam ua tau zoo, uas yog qhov yuav tsum tau ua rau loj - nplai kev tsim kho ntawm cov kav dej hlau. PSL2 qib yuav tsum muaj cov pa roj carbon sib npaug (CEIIW) Tsawg dua lossis sib npaug ntawm 0.43 thiab Pcm Tsawg dua lossis sib npaug li 0.25, kom ntseeg tau tias muaj zog thiab tiv taus txias tawg hauv tshav kub- thaj tsam cuam tshuam hauv thaj chaw vuam.
Cov ntsiab lus tseem ceeb Welding:
• Tsawg tus nqi CE:
Ua tau zoo txo qhov nyiam ntawm vuam cua sov- thaj tsam cuam tshuam kom tawv thiab txo qhov kev pheej hmoo ntawm cov kab mob khaub thuas
• Tsawg- phom sij- ntsiab lus:
S Tsawg dua los yog sib npaug rau 0.030% (PSL1) / Tsawg dua lossis sib npaug li 0.015% (PSL2), kom ntseeg tau cov purity ntawm welds thiab cov hlau puag
• Haum rau ntau txoj kev vuam:
taub qab vuam ntawm seamless steel kav, submerged arc vuam ntawm kauv / ncaj seam welded kav, thiab lwm yam., nrog zoo teb nplhaib vuam kev ua tau zoo
Rau qib PSL1, qhov txwv sab saud ntawm cov ntsiab lus carbon yog qhov dav (tsawg dua lossis sib npaug li 0.26%), thiab preheating ntawm 100-150℃raug pom zoo thaum vuam; rau qib PSL2, cov pa roj carbon ntsiab lus yuav tsum nruj dua (tsawg dua lossis sib npaug ntawm 0.16-0.18%), ua rau muaj kev sib txuas zoo dua thiab feem ntau tsis xav tau tshwj xeeb preheating lossis tsuas yog xav tau qis dua preheating.
Zoo qis -kub toughness thiab tsis kam rau kev ua haujlwm tawg tawg
API 5L Gr.B PSL2 yuav tsum tau Charpy V-kev ntsuas kev cuam tshuam los xyuas kom meej cov khoom tiv thaiv kom tawg tawg nyob rau hauv qis- qhov kev pabcuam kub. Qhov zoo-grained microstructure tau los ntawm normalization lossis TMCP cov txheej txheem txhim kho cov khoom qis- qhov kub thiab txias, ua rau Gr.B pipeline steel tuaj yeem siv tau rau hauv cov cheeb tsam txias thiab ib puag ncig nrog lub caij kub hloov pauv loj.
Yam cuam tshuam toughness Performance index (PSL2):
• Kev ntsuas kub: Feem ntau -20℃lossis qis dua (raws li tus neeg siv yuav tsum tau ua)
• Yam tsawg kawg nkaus lub zog: Ntau dua lossis sib npaug ntawm 27 J (tus nqi nruab nrab) / Ntau dua lossis sib npaug rau 20 J (tus nqi ib leeg)
Zoo corrosion kuj thiab ib puag ncig adaptability
API 5L Gr.B nthuav tawm zoo tiv thaiv corrosion tsis zoo nyob rau hauv ib txwm atmospheric, dej tshiab, av, thiab roj thiab gas media. Rau qhov chaw ua haujlwm acidic (muaj H₂S), cov ntaub ntawv tshwj xeeb uas tau teev tseg hauv Cov Ntawv Ntxiv J ntawm API 5L PSL2 (acid-cov kav dej) yuav tsum raug xaiv, nrog rau kev tswj ntxiv ntawm cov ntsiab lus sulfur, hardness, thiab HIC tsis kam.
Rau ib puag ncig marine, Appendix H thiab Appendix J ntawm PSL2 muab cov khoom siv ntxiv uas yuav tsum tau siv rau cov kav dej sab nrauv thiab cov kav dej hauv qab.
Zoo txias khoov thiab kev ua haujlwm zoo
API 5L Gr.B muaj cov ntsiab lus qis dua thiab cov txiaj ntsig nruab nrab- rau -tensile piv (feem ntau Tsawg dua lossis sib npaug rau 0.93 rau PSL2), uas muab nws zoo txias khoov formability. Nws yog tsim rau txias khoov yeeb nkab ntau lawm thiab yuav siv tau los tsim kub khoov los ntawm kub dabtsi yog khoov txheej txheem. Nws kuj pom zoo shearing, blanking, thiab yob txoj kev ua haujlwm nyob rau hauv coil thiab phaj tej yam kev mob.
Technical Specifications
Tshuaj muaj pes tsawg leeg (API Spec 5L / ISO 3183)
|
Lub ntsiab |
PSL1 Seamless Tube |
PSL1 welded yeeb nkab |
PSL2 |
Nco tseg |
|
C |
Tsawg dua lossis sib npaug li 0.28% |
Tsawg dua lossis sib npaug li 0.26% |
Tsawg dua lossis sib npaug li 0.16-0.18% |
Tsawg- carbon tsim los xyuas kom meej weldability thiab qis- kub toughness |
|
Mn |
Tsawg dua lossis sib npaug li 1.30% |
Tsawg dua lossis sib npaug li 1.30% |
Tsawg dua lossis sib npaug li 1.30% |
Kev daws teeb meem ntxiv dag zog, txhim kho lub zog |
|
P |
Tsawg dua lossis sib npaug li 0.030% |
Tsawg dua lossis sib npaug li 0.030% |
Tsawg dua lossis sib npaug li 0.025% |
Cov khoom tsis zoo, tswj nruj heev |
|
S |
Tsawg dua lossis sib npaug li 0.030% |
Tsawg dua lossis sib npaug li 0.030% |
Tsawg dua lossis sib npaug li 0.015% |
Cov khoom tsim kev puas tsuaj, tswj nruj me ntsis kom ntseeg tau tias qis -kub toughness |
|
Si |
Tsawg dua lossis sib npaug li 0.45% |
Tsawg dua lossis sib npaug li 0.45% |
Tsawg dua lossis sib npaug li 0.45% |
Deoxidizer, txhim kho lub zog |
|
V |
Tsawg dua lossis sib npaug li 0.05% |
Tsawg dua lossis sib npaug li 0.05% |
Tsawg dua lossis sib npaug li 0.05% |
Microalloying cov ntsiab lus, nag lossis daus muaj zog |
|
Nb |
Tsawg dua lossis sib npaug li 0.05% |
Tsawg dua lossis sib npaug li 0.05% |
Tsawg dua lossis sib npaug li 0.05% |
Microalloying ntsiab, tswj dov rau nplua nplej |
|
Ti |
Tsawg dua lossis sib npaug li 0.04% |
Tsawg dua lossis sib npaug li 0.04% |
Tsawg dua lossis sib npaug li 0.04% |
Microalloying cov ntsiab lus, nag lossis daus muaj zog |
|
CEIIW |
- |
- |
Tsawg dua lossis sib npaug li 0.43% |
Carbon sib npaug, tswj weldability |
|
Pcm |
- |
- |
Tsawg dua lossis sib npaug li 0.25% |
Crack Sensitivity Index |
|
Fe |
Cov khoom seem (≈ 97%) |
Cov khoom seem (≈ 97%) |
Cov khoom seem (≈ 97%) |
Matrix element |
Lub cev muaj zog
|
Khoom |
Tus nqi / Ntau |
Kev Xeem |
|
Qhov ntom |
7.85 g / cm³ |
Chav ntsuas kub (20 degree) |
|
Melting Point |
≈ 1420-1460 degree |
--- |
|
Elastic modulus |
Qhov siab tshaj plaws ntawm qhov siab ntawm GPa |
Chav ntsuas kub |
|
Thermal conductivity |
≈ 50 W/(m·K) |
Chav ntsuas kub |
|
Coefficient ntawm Thermal Expansion (20-100 degree) |
≈ 12.0 × 10⁻⁶ /K |
--- |
|
Poisson tus ratio |
≈ 0.28 |
Chav ntsuas kub |
Mechanical Properties (Tus nqi zoo)
|
Kev ua tau zoo |
PSL1 |
PSL2 |
Cov qauv kev coj ua |
|
Yam tsawg kawg nkaus Yield Strength |
245 MPa rau |
245 MPa rau |
API Spec 5L / ISO 3183 Daim Ntawv Pov Thawj |
|
Maximum Yield zog |
- |
450 MPa |
API Spec 5L / ISO 3183 Daim Ntawv Pov Thawj |
|
Yam tsawg kawg Tensile Strength |
415 MPa rau |
415 MPa rau |
API Spec 5L / ISO 3183 Daim Ntawv Pov Thawj |
|
Maximum Tensile Strength |
- |
655 MPa ua |
API Spec 5L / ISO 3183 Daim Ntawv Pov Thawj |
|
Elongation |
Ntau dua lossis sib npaug li 30% |
Ntau dua lossis sib npaug li 30% |
API Spec 5L |
Lus Cim: Cov 'B' hauv API 5L Gr.B stands rau qib Basic, nrog qhov tsawg kawg nkaus yield zog ntawm 35,000 psi (kwv yees li 245 MPa). GrB zoo ib yam li ASTM A53 Gr.B hais txog cov tshuaj lom neeg muaj pes tsawg leeg thiab cov khoom siv kho tshuab, thiab lawv feem ntau siv sib hloov hauv kev siv engineering.
Siv tau Media
1. Natural gas, roj av, thiab cov roj ua kom zoo:
Cov kab lub cev tseem ceeb thiab cov kab ceg ntev ntev - nrug nruab nrab thiab qis - kev sib kis.
2. Dej thiab slurries:
Cov kav dej, kev thauj mus los slurry.
3. Tshuaj lom neeg:
Cov kav dej hauv cov nroj tsuag tshuaj.
4. Nroog Gas:
Hauv nroog nruab nrab thiab qis - cov pa hluav taws xob faib hluav taws xob.
5. Cov kav dej muaj zog:
Lub tsev tsim, offshore platform neeg xyuas pib tsho (tsis yog-ib puag ncig corrosive).
6. General corrosive ib puag ncig:
Pa av, huab cua, dej tshiab.
Nco tseg: API 5L Gr.B tsis haum rau siab -kub, siab - siab, muaj zog acidic media (xws li siab - kub concentrated hydrochloric acid thiab hydrofluoric acid). Nyob rau hauv acidic roj thiab roj ib puag ncig uas muaj H₂S, cov ntaub ntawv qib tshwj xeeb tau teev tseg hauv Cov Ntawv Ntxiv J ntawm API 5L PSL2 (acid-}cov kav dej) yuav tsum raug xaiv, nrog rau kev tswj ntxiv ntawm cov ntsiab lus sulfur, hardness, thiab HIC tsis kam ua haujlwm.
Cov Khoom Muag Khoom thiab Txheej Txheem Ua Haujlwm
Seamless steel yeeb nkab (Seamless)
Txheej Txheem: Kub Rolling Piercing + Extension Rolling
Txoj kab uas hla: 21.3 - 1067 mm (1/2" - 42")
Phab ntsa thickness ntau: 2 - 150 hli
Nta: Seamless, siab siab- bearing peev xwm, haum rau siab - roj thiab roj mainlines
Cov ntawv thov ib txwm: siab- kev thauj mus los ntawm cov dej siab, roj thiab roj qhov chaw sib sau ua ke thiab xa cov kav dej
Ncaj Seam Siab -Frequency Resistance Welded Pipe (ERW)
Txheej txheem: Kub- dov coil → Txias dabtsi yog khoov txoj kev → High- zaus kuj welding
Sab Nrauv Qhov Loj: Feem ntau Tsawg dua lossis sib npaug li 610 mm (24 ")
Phab ntsa thickness ntau: Feem ntau Tsawg dua los yog sib npaug li 20 hli
Nta: High dimensional precision, high efficiency efficiency, thiab cov nqi tseem ceeb
Cov ntawv thov ib txwm: nruab nrab thiab qis- cov roj thiab cov kav dej siab, cov kav dej hauv nroog, thiab cov kav dej
Vuam Thaum tshav kub kub Input Control: High- zaus vuam ntawm ntau dua los yog sib npaug rau 100 kHz (PSL2 yuav tsum tau) kom ruaj khov weld zoo
Spiral Submerged Arc Welded Pipe (SSAW)
Txheej txheem: Kub- dov coil → Kauv txoj kev → Dual -sided submerged arc vuam
Sab Nraum Sab Nraud: Feem ntau 219 - 2500 hli
Phab ntsa thickness ntau: 6 - 25 hli
Nta: Qhov loj txoj kab uas hla muaj qhov zoo tshaj plaws, tso cai rau steel strips ntawm tib lub dav los tsim ntau yam diameters. Qhov kev ntxhov siab ntawm kauv welds tsuas yog 75-90% ntawm qhov ncaj seams, ua rau lawv tiv taus siab dua. Raws li txoj cai, lawv tuaj yeem ua tsis tu ncua hauv qhov ntev ntev.
Cov ntawv thov ib txwm: loj - txoj kab uas hla dej / roj xa hluav taws xob, lub tsho sab nrauv engineering
Ncaj Seam Submerged Arc Welded Pipe (LSAW)
Txheej Txheem: Hlau Phaj → JCOE Forming / UOE Forming → Dual -Sided Submerged Arc Vuam
Outer Diameter: 406 - 1620 hli (16" - 64")
Phab ntsa thickness ntau: 6 - 50 hli
Nta: luv welds, tsawg vuam cov khoom siv, ntau yam ntawm sab nraud txoj kab uas hla thiab phab ntsa thickness
Cov ntawv thov ib txwm: siab- siab ntev- cov kav xa mus rau qhov deb, cov kav dej hauv qab, cov roj thiab roj sib sau ua ke thiab kev thauj mus los mainlines
Siv tau Standards thiab Delivery Condition
Txuj: API Spec 5L, ISO 3183, GB / T 9711
Khoom Specification Level: PSL1 (Basic Level), PSL2 (Enhanced Level)
Kev xa khoom: Kub- dov, Tswj Rolling (TMCP), Normalized, Normalized Rolling, Kub Kho (Quenching + Tempering), thiab lwm yam.
Kev Ua Haujlwm Kawg: Flat Ends, Beveled Ends, Threaded Ends, Tshwj Xeeb Fitting Ends
Daim ntawv pov thawj: Thaum ua raws li PSL2 cov cai, yuav tsum tau muab daim ntawv pov thawj ua raws (SR15.1 yuav tsum tau ua) thiab tag nrho - txheej txheem traceability yuav tsum tau ua (SR15.2 yuav tsum tau ua).
Txoj Cai Kho Mob thiab Vuam Cov Ntsiab Lus
Qhov kawg kev ua tau zoo ntawm API 5L Gr.B nyob ntawm kub dov, normalized dov, los yog TMCP tswj dov thiab tswj cov txheej txheem txias:
1. Kub Rolling / Normalized Rolling (kom tau txais cov qauv microstructure thiab cov khoom siv kho kom zoo):
Yob ntawm 1050-1150 degree, ua haujlwm tswj dov hauv 800-900℃tiav qhov kub thiab txias, ua raws li cua txias. Ib qho zoo thiab nplua ferrite + pearlite microstructure tau txais, ua kom muaj kev sib tw zoo ntawm lub zog thiab tawv.
2. Tshaj tawm -weld Kev kho cua sov (yog tias xav tau):
Yog tias yuav tsum tau muaj kev ntxhov siab tom qab cov yeeb nkab nplhaib vuam vuam, tom qab- vuam cua sov kho ntawm 550-650℃rau 1-2 teev tuaj yeem ua tau. Kev kho cua sov tom qab vuam yuav tsum tau them sai sai rau kev tswj cov cua sov thiab cua txias kom tsis txhob cuam tshuam cov microstructure thiab cov khoom ntawm cov khoom siv hauv paus.
Lus ceeb toom tseem ceeb:
Nyob rau hauv cov pa roj thiab roj kis ib puag ncig yam tsis muaj H₂S, kev ntxhov siab kev kho cua sov feem ntau tsis tas yuav tsum tau tom qab vuam.
Rau cov kav xa dej hauv ib puag ncig acidic (muaj H₂S), nruj me ntsis ua raws li Daim Ntawv Ntxiv J ntawm API 5L PSL2 yuav tsum tau tiv thaiv kom tsis txhob muaj zog ntau dhau los ntawm kev tsis raug cai -weld heat treatment.
Thaum lub sij hawm vuam, kev tswj xyuas nruj ntawm cov khoom siv hluav taws xob thiab kev sib tshuam ntawm qhov kub thiab txias yuav tsum tau tiv thaiv cov nplej coarsening hauv tshav kub- cuam tshuam cheeb tsam.
API 5L Gr.B (L245) yog qhov tsim nyog rau nruab nrab thiab qis -cov roj thiab cov pa xa hluav taws xob, cov kav dej hauv nroog, thiab cov ntawv thov cov yeeb nkab. Nws raug pom zoo siv rau hauv cov chaw hauv qab no:
Daim ntawv thov teb
-
Roj thiab Natural Gas sib sau ua ke thiab thauj
● Internal oilfield sib sau ua ke thiab kev thauj mus los pipelines
● Gas teb raw roj sib sau ua ke thiab kev thauj mus los pipeline
● Ntev-kab kav kav ntev, cov kav xa dej -
Nroog gas pipeline network
● Nruab nrab thiab siab -siab roj kis tau tus mob thiab kev faib cov kav dej sib txuas
● Inlet thiab qhov hluav taws xob pipelines ntawm nroog gas siab tswj chaw nres tsheb -
Water Conveyance and Irrigation Engineering
● Ntev -kab dej xa mus rau qhov deb
● Agricultural irrigation main channel txhawb cov kav dej -
Chemical Engineering thiab Industrial Piping
● Tshuaj cog txheej txheem kav
● Chaw nres tsheb fais fab circulating dej yeeb nkab
● Cov dej txias muaj qhov system -
Tus Qauv Tubing
● Lub tsev steel qauv txhawb cov kav dej
● Offshore Platform Jacket (Tsis yog-Corrosive Areas)
● Cov kav dej rau cov pob zeb hauv paus
● Kev sib kis kab ntauwd cov yeeb nkab
Kev xa khoom thiab Customization
Peb muab cov kev daws teeb meem yooj yim thiab txhim khu kev qha kom ntseeg tau tias koj tau txais API 5L Gr.B kab yeeb nkab uas zoo kawg nkaus phim koj qhov kev xav tau.
|
Daim ntawv |
 Seamless Hlau
Yeeb |
 Ncaj Seam Resistance
Welded yeeb nkab (ERW) |
 Spiral Submerged Arc
Welded yeeb nkab (SSAW) |
 Ncaj Seam Submerged Arc
Welded Pipe (LSAW) |
|---|---|---|---|---|
|
Pauv ntau yam |
Sab nraud txoj kab uas hla: 21.3 - 1067 hli; |
Sab nraud txoj kab uas hla: 21.3 - 610 hli; Phab ntsa Thickness: 2 - 20 hli |
Sab nraud txoj kab uas hla: 219 - 2500 hli; Phab ntsa Thickness: 6 - 25 hli |
Sab nraud txoj kab uas hla: 406 - 1620 hli; Phab ntsa Thickness: 6 - 50 hli |
|
Customization Muaj peev xwm |
Kub-khoov seamless kav, tsau-ntev txiav, bevel machining, yeeb nkab kawg threads, tshwj xeeb kub kho tej yam kev mob |
Siab- zaus ncaj- seam welded kav, tsau -ntev txiav, bevel ua, galvanization / yas txheej kho |
Loj - txoj kab uas hla kauv welded kav, tsau-ntev txiav, bevel ua, tiv thaiv- txheej txheej (FBE/3PE) |
JCOE / UOE txoj kev, ntev txiav, bevel machining, tshwj xeeb yeeb nkab kawg kho |
Vim li cas thiaj xaiv peb? - Txhim khu kev qha Engineering Technology. Dependable xa khoom.
Peb tsis yog ib tus neeg muag khoom xwb, tab sis yog ib tus neeg koom tes nrog cov ntaub ntawv ntseeg siab rau koj hauv Suav teb.
Vertically Integrated Production
Muaj 20,000㎡ qhov chaw nrog 10+ automated kab (8, 000+ tons / xyoo). Hauv - tsev cuab yeej & qhov chaw tuag ua rau muaj kev hloov kho sai thiab tswj tus nqi zoo - tsis muaj tus neeg nruab nrab kos npe.
Kev Tswjhwm nruj nruj ntawm txhua theem
Tag nrho traceability nyob rau hauv lub tseem ceeb QC checkpoints thoob plaws hauv ntau lawm . 100% raws li ASTM/ASME, EN, thiab GB qauv. Cov ntaub ntawv xeem cov ntaub ntawv muaj nyob nrog txhua qhov khoom xa tuaj.
Txhim khu kev xa khoom & Export ntim
10+ xyoo xa tawm mus rau Tebchaws Europe, North America, Southeast Asia & Middle East nrog cov dej tsis zoo thiab tiv thaiv- xeb, ua ke nrog cov kev xaiv thauj khoom yooj yim kom muaj kev nyab xeeb thiab nyob rau - lub sijhawm tuaj txog.
Qauv validation ua ntej pawg ntau lawm
Peb muab cov qauv dawb rau kev kuaj xyuas zoo, tso cai rau koj tso cov xaj xaj tsuas yog tom qab kev pom zoo. Peb ua kom zoo sib xws los ntawm cov qauv mus rau cov khoom loj los ntawm qhov ntsuas qhov tseeb thiab kev tsim pob tshab.
FAQ
Q: Dab tsi yog qhov zoo ntawm API 5L Gr.B?
Q: Qhov txawv ntawm API 5L Gr.B PSL1 thiab PSL2 yog dab tsi? Yuav ua li cas xaiv ntawm lawv?
Q: Qhov txawv ntawm API 5L Gr.B, X42, X52, thiab X60 yog dab tsi? Yuav ua li cas xaiv ntawm lawv?
Q: Qhov siab tshaj plaws ua haujlwm kub rau API 5L Gr.B yog dab tsi?
Q: Dab tsi yog qhov vuam kev ua tau zoo ntawm API 5L Gr.B?
Q: Dab tsi yog qhov corrosion kuj ntawm API 5L Gr.B?
Q: API 5L Gr.B puas tuaj yeem hloov ASTM A53 Gr.B?
